Blackmagic Design MultiView 4; Multi-view router; for image control of four completely separate SDI video sources on a single display; Four 6G-SDI inputs with full resynchronization enable the monitoring of SD, HD and Ultra-HD video formats and frame rates in any combination and completely simultaneously; Can output content to 1080HD and 2160p displays, i.e. it can be connected to common HD and Ultra HD televisions; Various overlays such as audio level meters, user-defined labels and others can be shown in each view; Technical data :; SDI video input: 4x 10-bit SD-SDI, HD-SDI and 6G-SDI; SDI video output with loop through: 4x 10-bit SD-SDI, HD-SDI and 6G-SDI; SDI video output for multiple display: 1x 10-bit HD-SDI; HDMI video outputs for multiple display: 1x HDMI Type A supports the EDID data of the monitor; Reclocking; Control: via Ethernet (RJ-45), USB 2.0 or Teranex Mini Smart Panel (optionally available # 485905); Power supply: IEC power cable required. 90 - 240 V AC input voltage or Power Over Ethernet (48 V DC via PoE); Power consumption: approx. 16 W; dimensions (WxHxD): 14 x 4.42 x 17 cm; Weight: approx. 580 g
